Understanding the Measure Phase in Lean Six Sigma
The Measure phase serves as the bridge between identifying a problem and implementing solutions. During this critical stage, practitioners collect data, establish baselines, and most importantly, document processes in detail. Process mapping emerges as an indispensable tool during this phase, enabling teams to visualize the current state of operations, identify bottlenecks, and establish a foundation for improvement initiatives. You might also enjoy reading about Measure Phase: Creating Effective Data Collection Plans for Process Improvement Success.
For organizations dealing with complex workflows that involve multiple departments, handoffs, decision points, and interdependencies, effective process mapping becomes even more crucial. Without a clear visual representation, teams often struggle to identify waste, redundancies, and opportunities for improvement that may be hiding in plain sight. You might also enjoy reading about What is Measurement Systems Analysis and Why It Matters in Six Sigma.
The Importance of Process Mapping in Complex Workflows
Complex workflows present unique challenges that simple linear processes do not. Consider a healthcare organization managing patient admissions, where the workflow involves intake staff, nurses, physicians, insurance verification teams, and administrative personnel. Each touchpoint represents a potential delay, error, or inefficiency. Process mapping provides the clarity needed to navigate these intricacies. You might also enjoy reading about Measure Phase: A Comprehensive Guide to Conducting Gage Repeatability and Reproducibility Studies.
When properly executed, process mapping delivers several critical benefits:
- Enhanced visibility into actual versus perceived workflows
- Identification of non-value-added activities and waste
- Documentation of current state processes for baseline establishment
- Discovery of variation sources within the process
- Improved communication among stakeholders
- Foundation for data collection planning
- Basis for future state design and improvement initiatives
Core Process Mapping Techniques for Complex Workflows
1. SIPOC Diagrams (Suppliers, Inputs, Process, Outputs, Customers)
The SIPOC diagram serves as an excellent starting point for understanding complex workflows at a high level. This technique provides a 30,000-foot view before diving into detailed mapping exercises. SIPOC diagrams help teams define process boundaries and identify all key elements affecting process performance.
Practical Example: E-commerce Order Fulfillment Process
Let us examine a SIPOC diagram for an e-commerce company’s order fulfillment process:
Suppliers: Customers, payment processors, inventory management system, shipping carriers, warehouse staff
Inputs: Customer orders, payment information, product availability data, shipping addresses, packaging materials
Process: Receive order, verify payment, check inventory, pick items, package products, generate shipping label, dispatch order
Outputs: Shipped packages, tracking information, order confirmation emails, updated inventory records, delivery notifications
Customers: End consumers, customer service department, accounting department, inventory management team
This high-level view immediately reveals the interconnected nature of the workflow and helps teams understand which elements require deeper investigation during detailed process mapping.
2. Detailed Process Flow Maps
Once the SIPOC establishes boundaries, detailed process flow maps drill down into the step-by-step activities within the workflow. These maps use standardized symbols to represent different types of activities, decisions, and process elements.
Sample Data Set: Customer Service Complaint Resolution
Consider a telecommunications company handling customer complaints. A detailed process flow map would document each step:
Step 1: Customer initiates complaint (Phone: 60%, Email: 25%, Chat: 15%)
Step 2: Initial representative receives complaint (Average time: 3 minutes)
Step 3: Representative accesses customer account (Average time: 2 minutes)
Step 4: Representative reviews complaint history (Average time: 4 minutes)
Step 5: Decision point: Can first-level representative resolve? (Yes: 40%, No: 60%)
Step 6a: If yes, representative implements solution (Average time: 8 minutes)
Step 6b: If no, escalate to specialist (Wait time: 15-45 minutes)
Step 7: Specialist reviews case (Average time: 10 minutes)
Step 8: Specialist implements solution (Average time: 20 minutes)
Step 9: Follow-up call scheduled (2-3 days later)
Step 10: Case closure and documentation (Average time: 5 minutes)
This detailed mapping immediately highlights that 60% of complaints require escalation, creating a significant bottleneck and extended resolution times. The data reveals an average total resolution time of 67 minutes for escalated cases versus 22 minutes for first-level resolutions.
3. Swimlane Diagrams (Cross-Functional Flowcharts)
Swimlane diagrams excel at visualizing complex workflows involving multiple departments or roles. By organizing process steps into horizontal or vertical lanes representing different actors, these diagrams clarify responsibilities and reveal handoff points where delays and errors commonly occur.
Real-World Example: New Employee Onboarding Process
An organization with 500+ employees might map their onboarding process across four swimlanes:
HR Department Lane:
- Send offer letter (Day 1)
- Collect new hire documentation (Days 1-3)
- Enter employee into HRIS system (Day 4)
- Schedule orientation session (Day 5)
- Conduct orientation (Day 7-8)
IT Department Lane:
- Receive new hire notification (Day 3)
- Create network accounts (Day 4-5)
- Procure hardware (Day 4-6)
- Configure systems (Day 5-7)
- Deliver equipment (Day 7)
Facilities Department Lane:
- Receive workspace request (Day 3)
- Prepare workstation (Day 4-6)
- Install furniture if needed (Day 5-6)
- Conduct workspace inspection (Day 6)
Direct Manager Lane:
- Submit onboarding request (Day 1)
- Prepare training schedule (Days 2-5)
- Welcome employee (Day 7)
- Conduct department orientation (Day 8-9)
- Begin job-specific training (Day 10+)
Sample data from this organization revealed that 35% of new hires did not have fully functional workstations on their first day, primarily due to coordination failures between IT and Facilities. The swimlane diagram made these handoff issues visible, enabling the team to implement a coordination checkpoint at Day 5.
4. Value Stream Mapping
Value stream mapping takes process documentation to another level by distinguishing between value-added and non-value-added activities. This technique calculates cycle times, wait times, and process efficiency ratios, providing quantitative data that supports improvement initiatives.
Practical Application: Manufacturing Order Processing
A manufacturing company producing custom machinery mapped their order-to-delivery value stream with these findings:
Sales Order Entry: Process time 30 minutes, Wait time 2 hours (Value-added)
Engineering Review: Process time 4 hours, Wait time 24 hours (Value-added)
Approval Queue: Process time 10 minutes, Wait time 48 hours (Non-value-added)
Materials Planning: Process time 2 hours, Wait time 8 hours (Value-added)
Procurement: Process time 1 hour, Wait time 120 hours (5 days) (Necessary non-value-added)
Manufacturing: Process time 40 hours, Wait time 16 hours (Value-added)
Quality Inspection: Process time 4 hours, Wait time 8 hours (Value-added)
Shipping Preparation: Process time 2 hours, Wait time 24 hours (Value-added)
Total process time: 53.7 hours (2.2 days)
Total wait time: 250 hours (10.4 days)
Total lead time: 303.7 hours (12.6 days)
Process efficiency: 17.7%
This value stream map revealed that less than 18% of the total lead time added value for the customer. The 48-hour approval queue stood out as a prime target for improvement, representing pure waste with no value contribution.
5. Spaghetti Diagrams
For workflows involving physical movement of people, materials, or information, spaghetti diagrams provide powerful visual evidence of inefficiency. These diagrams overlay the path of movement onto a physical layout or system architecture diagram.
Case Study: Hospital Emergency Department Patient Flow
A hospital emergency department mapped patient and staff movement over a typical 12-hour shift. The resulting spaghetti diagram revealed:
Average patient journey covered 420 feet across 8 different locations: Triage station, waiting area, examination room, imaging department, laboratory, treatment area, consultation room, discharge station.
Nursing staff walked an average of 4.2 miles per shift, with 60% of movement attributed to retrieving supplies, accessing computers, and coordinating with other departments.
The visual representation showed crossing paths, backtracking, and unnecessary movement patterns that contributed to a median patient throughput time of 4.5 hours. After implementing process improvements informed by the spaghetti diagram analysis, the department reduced median throughput to 3.2 hours and nursing staff walking distance by 35%.
Best Practices for Process Mapping Complex Workflows
Engage the Right Stakeholders
Successful process mapping requires input from individuals who actually perform the work daily. While managers provide valuable perspective, frontline employees possess intimate knowledge of workarounds, informal procedures, and hidden complexities that formal documentation often misses. Assemble cross-functional teams representing all roles touched by the process.
Map the Current State First
Resist the temptation to map the ideal process or how procedures should work according to documentation. Focus exclusively on documenting reality, including all variations, exceptions, and informal practices. This honest assessment provides the baseline necessary for measuring improvement.
Collect Supporting Data
Process maps gain power when supported by quantitative data. For each process step, collect metrics such as:
- Cycle time (how long the activity takes)
- Wait time (time between activities)
- Error rates or defect percentages
- Volume or throughput numbers
- Resource requirements
- Cost per transaction
These data points transform process maps from simple diagrams into analytical tools that support data-driven decision making.
Verify and Validate
Once the initial process map is complete, validate it through multiple channels. Walk through the actual process while referencing the map, conduct review sessions with subject matter experts, and test the documentation with new team members to ensure clarity and accuracy.
Focus on Critical to Quality Characteristics
Complex workflows contain numerous activities, but not all equally impact quality or customer satisfaction. Identify Critical to Quality (CTQ) characteristics and ensure your process mapping pays special attention to activities affecting these factors. For example, in pharmaceutical manufacturing, steps involving dosage accuracy would receive more detailed documentation than administrative paperwork.
Common Challenges and Solutions
Challenge: Process Variation
Complex workflows rarely follow a single path. Different scenarios, exceptions, and special cases create multiple process variants.
Solution: Document the primary workflow representing 80% of cases first, then create separate maps for significant variations. Use decision trees to show branch points where processes diverge based on specific conditions.
Challenge: Information Overload
Attempting to capture every detail in a single map creates cluttered, unusable documentation.
Solution: Employ hierarchical mapping with multiple levels of detail. Start with high-level SIPOC or level-one process maps, then create detailed sub-process maps for areas requiring deeper analysis.
Challenge: Resistance from Team Members
Employees may fear that documenting inefficiencies will reflect poorly on their performance or lead to job elimination.
Solution: Establish psychological safety by emphasizing that process improvement targets systems, not people. Highlight that frontline employees are valued experts whose insights are essential for improvement. Share success stories showing how process improvement creates better working conditions.
Integrating Process Maps with Lean Six Sigma Measurement Tools
Process maps do not exist in isolation within the Measure phase. They integrate with other Lean Six Sigma tools to create comprehensive process understanding:
Data Collection Plans: Process maps identify where and what to measure, informing the development of targeted data collection strategies.
Measurement System Analysis: The process map highlights measurement points where gauge R&R studies or other measurement system analyses should be conducted.
Capability Studies: By identifying process inputs and outputs, process maps guide capability analysis to determine if processes can meet specifications.
FMEA (Failure Mode and Effects Analysis): Process maps provide the foundation for systematic failure mode identification and risk assessment.
Digital Tools and Technology for Process Mapping
While process mapping can be accomplished with paper and markers during team workshops, digital tools offer advantages for complex workflows:
Software platforms like Microsoft Visio, Lucidchart, Miro, and specialized Lean Six Sigma applications provide templates, standardized symbols, and collaboration features. These tools enable version control, easy updates, and integration with data analysis software.
Process mining software represents an emerging category that automatically discovers process maps by analyzing event logs from information systems. This technology proves especially valuable for complex workflows spanning multiple systems where manual documentation would be prohibitively time-consuming.
Measuring Success: Key Performance Indicators for Process Mapping
How do organizations know if their process mapping efforts during the Measure phase are effective? Consider these indicators:
- Stakeholder agreement rate on process documentation accuracy
- Number of previously unknown process variations discovered
- Percentage of process steps with associated measurement data
- Time reduction in new employee training after implementation
- Increase in improvement ideas generated by teams
- Reduction in miscommunication incidents between departments
Moving from Measure to Analyze
Process mapping in the Measure phase creates the foundation for the Analyze phase. With comprehensive process documentation and supporting data, teams can apply statistical analysis, root cause investigation, and hypothesis testing to identify improvement opportunities.
The process maps serve as reference points throughout the remaining DMAIC phases, providing
